Janisol Custom Steel Windows

The slender profile face widths of Janisol windows provide the space for creativity and lend the building a quite special character. Whether it is sash bar variants, arched windows or large-glazed elements: the Janisol window system is particularly suitable for use in new buildings as well as for the refurbishment of existing buildings.



Product details



Materials / surface finishes

​

  • Uncoated steel or strip-galvanised steel, suitable for powder-coating or stove-enamelling



Window and opening types

​

  • Single- and double-vent windows, with and without fixed side panels or transoms

  • Side-hung, turn-tilt, bottom-hung, top-hung and double-vent windows

  • Horizontal pivot windows

  • Fixed lights



Equipment

​

  • Concealed or surface-mounted fittings

  • Integrated or fitted electric drives



Special technical features

​

  • Installation depth 60/64 mm

  • Special geometries (circular arches, trapezoidal windows etc.)

  • Structural glazing openings as special solution

  • Vent weights up to 180 kg



Test certificates

​

CE marking in accordance with product standard EN 14351-1

    •    Tightness against heavy rain until class 8A

    •    Air permeability until class 4

    •    Resistance to wind load until class C4

    •    Airborne sound insulation until Rw 45 db

    •    Coefficient of thermal transmittance Uw > 1.3 W/m2K

    •    Shear connection in accordance with EN 14024

    •    Burglary protection in accordance with EN 1627 until RC (WK) 3

    •    Bullet proofing until 6



Janisol Custom Steel Doors

Thanks to its highly resistant material characteristics, steel is perfect for high traffic buildings such as schools, hospitals, sports centers etc. Stainless steel adds a graceful look and reduces maintenance to a minimum. Janisol stainless steel is therefore the right choice for shopping malls, railway stations, banks and hotels.



Product details



Materials / surface finishes

​

  • Stainless steel 1.4401 untreated or polished



Element types



  • Single- and double-leaf doors with and without fixed side panels or transoms

  • Anti-finger-trap doors



Equipment

  • Welded or screw-on hinges in stainless steel

  • Integrated door closers

  • Designer glazing frames

  • Emergency locks and panic push-bars



Special technical features

​

  • Pivot door as special solution



Test certificates

​

CE marking in accordance with product standard EN 14351-1

    •    Tightness against heavy rain until class 4A

    •    Air permeability until class 4

    •    Resistance to wind load until class C4/B4

    •    Airborne sound insulation until Rw 45 db

    •    Coefficient of thermal transmittance UD > 1.5 W/m2K

    •    Shear connection in accordance with EN 14024

  • Long-term function in accordance with EN 12400 class 8

  • Burglary protection in accordance with EN 1627 until RC (WK) 3

  • Bullet proofing FB 4-6

  •  Emergency exit doors in accordance with EN 1125 / EN 179
